TD-V710

contact us >

Technical specifications
TD-V710 5W Analog Radio
VHF 136-174mhz UHF 400-520MHz

Wirelesss Clone Two Way Radio
General
Frequency Range
VHF: 136-174MHz
UHF:400- 520MHz

Channel Capacity
16
Wireless Clone
Yes
Bluetooth Programming
Optional
PTT ID
Yes
DTMF
Yes
SOS
Yes
VOX
Yes
Remote Stun/Kill/Activate
Yes
Channel Spacing
12.5/25.0 KHz
Operation Voltage
7.4V
Battery Capacity
2000mAh (Li-ion)
Battery Life(5-5-90 Duty Cycle)
About 20 Hours
Frequency Stability
+2.5ppm
Operating Temperature
-20~+ 60°C
Antenna Impedance
50Ω
Dimension( Hx Wx D) (Without Antenna)
113 x 52x 32mm
Weight (With Antenna& Battery)
261g
Transmitter
RF Power Output
5W/4W
Modulation Type
-36dBm<1GHz; -30dBm> 1GHz
FM Noise
45/40dB
Audio Distortion
≤5%
Modulation Limiting
±2.5KHz@12.5KHz;
±5.0KHz@25KHz

Audio Response
+1to-3dB
Receiver
Sensitivity
≤0.30/0.20μV
Adjacent Channel Selectivity
60/70dB
Intermodulation
70dB
S/N
45/40dB
Audio Power Output
600mW
Audio Distortion
≤5%
Standard Accessories
