General Specifications |
||||||
| Frequency Range |
|
VHF 136-174MHz UHF: 400-470MHz |
|
Number Of Channels |
|
48 |
| Channel Spacing |
|
Analog:25/12.5KHz Digital: 12.5KHz |
|
Operating Voltage |
|
7.4V |
| Standard Battery |
|
1500mah (Lithium Ion) |
|
Battery Average Working Hours（5-5-90Working Cycle） |
|
About 14 Hours |
| Frequency Stability |
|
±1.0 PPM |
|
Operating Temperature Range |
|
-20℃~+55℃ |
| Antenna Impedance |
|
50Ω |
|
Dimensions（HxWxD）（With out Antenna） |
|
105 x 53 x 30mm |
| Weight(Including Antenna And Battery) |
|
199g |
|
|||
|
Transmitter |
||||||
| Output Power |
|
UHF: 4.0W/1.5W |
|
Modulation(Analog) |
|
11KΦF3E@12.5KHz 16KΦF3E@25KHz |
| Modulation(Digital) |
|
12.5KHz Data And Voice 7K60FXW.Date7K60FXD |
|
Clutter And Harmonics |
|
-36dBm<1ghz -30dbm="">1GHz |
| Signal To Noise Ratio |
|
40/45dB |
|
Audio Distortion |
|
≤3% |
| Modualation Limit |
|
±2.5@12.5KHz；±5.0@25KHz |
|
Audio Rseponse（300~3000HZ） |
|
+1to-3dB |
| Digital Vocoder Type |
|
AMBE++ |
|
Digital Protocal |
|
ETSI-TS102 361-1.-2.-3 |
|
Receiver |
||||||
| Sensitivity(Analog) |
|
≤0.20µV（12dB SINAD） |
|
Sensitivity(Digital) |
|
≤0.20µV/BER3% |
| Adjacent Channel Selsetivity |
|
≥60dB |
|
Intermodulation |
|
≥60dB |
| Spurious Response Suppression |
|
≥60dB |
|
Signal To Noise Ratio |
|
40/45dB |
| Audio OutPut Power |
|
≥500mW |
|
Audio Distortion |
|
≤5% |
| Audio Resopnse |
|
+1~-3dB |
|
Conduction Emission Miscellaneous |
|
<-57dBm |
